Prometheus relabel_configs Explained: A Practical Guide

A target you expected to scrape never shows up in Prometheus. No error in the logs, no failed scrape, nothing red on the targets page — the series just isn’t there. You add --log.level=debug, restart, squint at the output, and eventually find it: a keep rule three lines into your relabel_configs quietly dropped the target because the regex didn’t match the way you assumed. That silent failure is the whole reason relabel_configs deserves a careful read. Prometheus relabeling rewrites, keeps, or drops targets and their labels, and when it’s wrong it doesn’t complain — it just discards your metrics.

This guide walks through Prometheus relabeling from the ground up: what it does, the fields every rule is built from, and each action with a small example. The semantics here match exactly what the engine in the Prometheus Relabel Tester implements, so you can paste any snippet below into it and watch the labels change.

What relabeling actually does

Section 1 of 6 · ~1 min

Relabeling runs over a label set and produces a new label set. That’s it. Every target Prometheus discovers arrives as a bag of labels — its address, its job, and a pile of __meta_* labels from service discovery. Before the scrape happens, your relabel_configs rules run top to bottom over those labels. Each rule sees the output of the one before it.

A rule can do one of three things to that label set:

• Rewrite a label (or create one) — replace, labelmap, lowercase, uppercase, hashmod.
• Drop the whole target so it’s never scraped — keep, drop, keepequal, dropequal.
• Remove individual labels by name — labeldrop, labelkeep.

scrape_configs:
  - job_name: api
    static_configs:
      - targets: ["10.0.0.5:8080"]
    relabel_configs:
      - source_labels: [__address__]
        target_label: instance

After this rule runs, the target carries an instance label copied from __address__. Nothing errored, nothing was dropped — one label was rewritten. That is the entire job of relabeling, repeated rule by rule.

There are two places relabeling runs. relabel_configs runs before the scrape, on the target’s discovery labels, and can keep or drop whole targets. metric_relabel_configs runs after the scrape, on every sample’s labels, and is used to drop or rewrite individual time series. Same actions, same semantics — only the timing and the input differ.

The building blocks: source_labels, separator, regex, modulus, target_label, replacement, action

Section 2 of 6 · ~2 min

Every relabel rule is assembled from the same handful of fields. Most have defaults, so a rule rarely sets all of them.

- source_labels: [job, instance]   # which label values to read
  separator: ";"                   # how to join them (default ";")
  regex: "(.*);(.*)"               # pattern to match the joined value (default "(.*)")
  modulus: 8                       # only for hashmod
  target_label: combined           # label to write (required by some actions)
  replacement: "$1-$2"             # value to write, with $1/${1} expansion (default "$1")
  action: replace                  # what to do (default "replace")

Here’s how a rule processes that. Prometheus reads each name in source_labels, looks up its value (a missing label reads as the empty string), and joins them with separator. The default separator is a single semicolon, so source_labels: [job, instance] on job="api", instance="10.0.0.1:9090" produces the joined value api;10.0.0.1:9090.

That joined value is matched against regex. The one detail that catches everyone: the regex is fully anchored. Prometheus wraps your pattern as ^(?:your-regex)$, so it must match the entire joined value, not just part of it.

# This does NOT match "api-server" — the regex must match the whole value.
- source_labels: [job]
  regex: api
  action: keep

A regex: api rule will not keep a target whose job is api-server, because ^(?:api)$ only matches the literal string api. You’d need api.* or (api.*). This single fact explains the majority of “my target vanished” mysteries.

When the regex matches and the action writes a label, replacement supplies the value. Capture groups expand as $1, ${1}, or named groups $name/${name}; the default replacement is $1, which is why a bare replace with regex: (.*) copies the source value through unchanged. modulus is only read by hashmod, and target_label is required by replace, hashmod, lowercase, uppercase, keepequal, and dropequal.

The actions one by one: replace, keep, drop, labelmap, labelkeep, labeldrop, hashmod

Section 3 of 6 · ~3 min

Prometheus supports eleven actions. Each example below is a complete, runnable rule.

replace

Join the source labels, match the regex, expand $1/${1} in replacement, and set target_label.

- source_labels: [__address__]
  regex: "([^:]+):.*"
  target_label: ip
  replacement: "$1"

__address__="10.0.0.5:8080" becomes a new label ip="10.0.0.5". If the regex doesn’t match, the label set is left unchanged. There’s a sharp edge worth memorizing: if the expanded replacement is the empty string, replace deletes the target label instead of setting it to blank.

# When tmp_instance is empty, this DELETES the instance label.
- source_labels: [tmp_instance]
  regex: "(.+)"
  target_label: instance
  replacement: "$1"

On instance="old", tmp_instance="", the regex (.+) fails to match an empty value, so nothing happens — instance survives. But change the source so the expansion lands on an empty string and the instance label disappears entirely. That asymmetry is a frequent source of “where did my label go?“

keep

Drop the whole target unless the joined source matches the regex.

- source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_scrape]
  action: keep
  regex: "true"

Only pods annotated prometheus.io/scrape: "true" survive; everything else is dropped before scraping. keep is an allow-list gate.

drop

The mirror of keep: drop the target when the joined source does match.

- source_labels: [__name__]
  action: drop
  regex: "go_gc_.*"

Used in metric_relabel_configs, this silences the entire go_gc_* metric family before it’s stored. drop is a deny-list gate.

labelmap

labelmap operates on label names, not values. For every label whose name matches the regex, it sets a new label — named by the expanded replacement — to that label’s value.

- action: labelmap
  regex: "__meta_kubernetes_pod_label_(.+)"

A label __meta_kubernetes_pod_label_app="api" produces a new label app="api". This is the canonical move for promoting Kubernetes pod labels to plain labels. The default replacement of $1 is what writes the captured suffix as the new name.

labelkeep / labeldrop

Both filter labels by name. labeldrop removes every label whose name matches; labelkeep removes every label whose name does not match.

# Strip all leftover service-discovery metadata.
- action: labeldrop
  regex: "__meta_.+"

# Keep only the four labels you care about; drop everything else.
- action: labelkeep
  regex: "(__name__|job|instance|severity)"

hashmod

hashmod sets target_label to a stable shard number. It takes the MD5 of the joined source, reads the last 8 bytes of that digest as a big-endian 64-bit integer, and stores hash % modulus.

- source_labels: [__address__]
  action: hashmod
  modulus: 3
  target_label: __tmp_shard

Every target gets a deterministic __tmp_shard value of 0, 1, or 2. The MD5 recipe matters: the Relabel Tester reproduces this exact byte-for-byte, so the shard values it shows are the values Prometheus will compute.

keepequal / dropequal

These two take no regex. They compare the joined source value to the current value of target_label and keep or drop on equality.

# Drop the target if its port already equals the discovered one.
- source_labels: [__meta_port]
  action: dropequal
  target_label: port

keepequal keeps only when the two are equal; dropequal drops when they’re equal.

lowercase / uppercase

Set target_label to the lower- or upper-cased joined source value — handy for normalizing case-inconsistent discovery labels.

- source_labels: [environment]
  action: lowercase
  target_label: environment

environment="PRODUCTION" becomes environment="production".

_meta labels from service discovery and why they matter

Section 4 of 6 · ~1 min

Every service discovery mechanism — Kubernetes, EC2, Consul, file-based — attaches __meta_* labels to each target it finds. These are only available during relabel_configs. They are stripped before the scrape, so if you want any of that metadata to survive as a real label, you have to copy it out with replace or labelmap first.

A Kubernetes pod target arrives looking roughly like this:

__address__="10.0.0.5:8080"
__meta_kubernetes_namespace="default"
__meta_kubernetes_pod_name="api-7d9f"
__meta_kubernetes_pod_label_app="api"
__meta_kubernetes_pod_annotation_prometheus_io_scrape="true"
__meta_kubernetes_pod_annotation_prometheus_io_port="9100"

The __meta_* labels are why relabeling exists at all. They carry the discovery context — which namespace, which annotations, which pod labels — that you turn into scrape decisions (keep on the scrape annotation) and into durable labels (labelmap the pod labels). Anything starting with a double underscore is internal and dropped after relabeling, with __name__ (the metric name) being the notable one that survives into storage. Because these labels only exist at relabel time, the only safe way to confirm a rule reads them correctly is to feed a realistic __meta_* set through your rules and look at the output.

Recipes you will reuse

Section 5 of 6 · ~1 min

These are the patterns that show up in almost every real scrape config.

Keep only prod targets

- source_labels: [__meta_kubernetes_namespace]
  action: keep
  regex: "prod|production"

Anchored, so prod matches the namespace prod exactly and staging-prod would not match unless you write .*prod.*. The | alternation keeps both naming conventions.

Drop noisy metrics (metric_relabel_configs)

metric_relabel_configs:
  - source_labels: [__name__]
    action: drop
    regex: "go_gc_.*|process_.*"

Runs after the scrape, dropping high-cardinality families before they hit storage.

hashmod sharding

The two-rule horizontal sharding pattern — hash into a temp label, then keep only the shard this Prometheus owns:

- source_labels: [__address__]
  action: hashmod
  modulus: 3
  target_label: __tmp_shard

- source_labels: [__tmp_shard]
  action: keep
  regex: "0"

Run this against four sample addresses in the tester and you’ll see exactly which two or three land on shard 0 and survive — the others are dropped, marked with the rule and action responsible.

Map SD labels with labelmap, then rewrite the address

# Promote every pod label to a plain label.
- action: labelmap
  regex: "__meta_kubernetes_pod_label_(.+)"

# Rebuild __address__ from the IP and an annotated port.
- source_labels: [__address__, __meta_kubernetes_pod_annotation_prometheus_io_port]
  action: replace
  regex: "([^:]+)(?::\\d+)?;(\\d+)"
  replacement: "$1:$2"
  target_label: __address__

The second rule shows the joined-source idiom in action: two source_labels joined by the default ; separator, with a regex written to account for that separator. __address__="10.0.2.4:8080" joined with port 9100 becomes 10.0.2.4:8080;9100, the regex captures 10.0.2.4 and 9100, and the address is rebuilt as 10.0.2.4:9100.

Test before you ship

Section 6 of 6 · ~1 min

Relabeling is the one part of a Prometheus config where being almost right produces no error and no warning — just missing or wrong series. The regex anchoring, the empty-replacement deletion, the MD5 hashmod, the join order of multiple source_labels: each is easy to get subtly wrong, and a live Prometheus won’t tell you which one bit you.

Paste the recipes from this post, with a realistic set of __meta_* labels, into the Prometheus Relabel Tester and you’ll see the joined value, the matched (or unmatched) regex, the per-label diff, and a clear flag — naming the rule and action — whenever a target is dropped. It runs entirely in your browser, so you can safely paste internal scrape configs.
